Knowledge Base Archives: Series 4

Monitor Series 4 Series 4 Service Instructions

Series 4: Monitor Replacement

1) Remove pin for old monitor. Please be careful of spring which will release when pin is removed. 2) Remove black washer, spring and monitor from bracket. 3) Insert new monitor through bracket on side. 4) Put new spring with zip ties on spigot tube, followed by the black washer. 5) Install R-Clip through the hole in spigot tube. ...
Monitor Series 4 Service Instructions

Series 4: Monitor Retrofit

Step 1- Remove the handle from the handle rests and place the handle in the full forward position as shown.  Step 2- Stand the WaterRower upright and disconnect the bungee as shown.   Step 3- Lay the WaterRower down. Remove the Tie Rods and JCB Bolts connecting the Top Deck to the Tank assembly as …

Series 4 Service Instructions

Series 4: Recoil Belt Buckle Replacement

Step 1- Pass the Recoil Belt through the bungee buckle with the belt facing the serrations on the buckle as shown.   Step 2- Pass the Recoil Belt through the D-ring and back through the bungee buckle as shown. The Recoil Belt should follow itself back through the buckle. It is advised that the loose …

Monitor Series 4 Service Instructions

Series 4: Monitor Sensor Replacement

For Video Instructions, click here: S4 Monitor Sensor Replacement Step 1- Remove the handle from the handle rests and place the handle in the full forward position as shown.   Step 2- Stand the WaterRower upright and disconnect the bungee as shown.   Step 3- Remove the Tie Rods and JCB bolts connecting the Top …

Series 4 Service Instructions

Series 4: Forward Riser Replacement

For Video Instructions, please see the following link: Replacing the Forward Riser Assembly Step 1- Detach the bungee from the recoil belt. Step 2- Remove handle assembly (see handle removal replacement instructions) Step 3- Remove Tie Rod bolts as shown. Step 4- Remove the fasteners connecting the forward riser bottom bracket to the side rails as …
