Knowledge Base Archives: Service Instructions

Series 2 Service Instructions

Series 2: Handle Replacement (Bolt on)

Step 1.  Remove the Handle from the handle rests and place the handle in the full forward position. Step 2. Pass the drive strap around the large pulley and underneath the top deck back towards the clutch housing. Pass the end of the drive strap inside (towards the centre of the machine) the drive strap …

Series 3 Service Instructions

Series 3: Tank Reseal

Please handle the tank carefully, as cracking either the top or bottom half would cause irreparable damage. If your tank has any cracks, you will need to replace it (WaterRower Part # WRPT004). Please read all instructions carefully before beginning any WaterRower service actions. Please view the WaterRower tank repair video at: http://www.waterrowerservice.com/videos We highly …

Series 3 Service Instructions

Series 3: Single Bungee Replacement

For Video Instructions, please see the following link: Replacing the S4 Bungee Assembly Step 1- Remove the Handle from the handle rests and place the handle in the full forward position. Step 2- Stand the WaterRower upright and disconnect the bungee from the Recoil Belt as shown. Step 3- Remove the Bungee from the Rear …

M1 Service Instructions

M1: Metal Clutch Replacement

For Video Instructions, click here: Replacing the Clutch (Plastic) Step 1- Remove the handle from the handle rests and place the handle in the full forward position as shown.   Step 2- Stand the WaterRower upright and disconnect the bungee as shown. Step 3- Lay the WaterRower down and slowly pull the handle so that …

M1 Monitor Service Instructions

M1: Wire Harness Replacement

Position the handle forward to the front Forward Riser pulley Carefully remove the Top Deck by removing the Top Deck bolts and upper Tie Rods. Gently lift the Top Deck up being careful not to dislodge any of the guide pulleys. Unclip the sensor connector from the wire harness. Remove the footboard handle rests, and loosen …

M1 Monitor Service Instructions

M1: Monitor Sensor Disk Alignment

If your S4 monitor is flashing zeros and not counting down, there is one simple check you can do that may solve the problem. You can check the position of the Sensor Disk. During shipping of your WaterRower Tank this Sensor Disk can slide slightly downwards. The diagram below shows the position of the Sensor …

A1/GX Service Instructions

A1/GX: Short Tank Assembly Replacement

Step 1. Remove the handle from the handle rests and place in the full forward position. Step 2. Stand the WaterRower upright and disconnect the bungee. Step 3. Lay the WaterRower down and pull the handle so the drive strap unwinds from the clutch housing. Remove the handle and drive strap from the clutch by unstrapping the …

A1/GX Service Instructions

A1/GX: Full Tank Assembly Replacement

Handle Removal Step 1.  Remove the Handle from the handle rests and place the handle in the full forward position Step 2.  Stand the WaterRower upright and disconnect the bungee from the recoil belt as shown Step 3.  Lay the WaterRower down and slowly pull the handle so that the drive strap unwinds from the …

Series 3 Service Instructions

Series 3: Top Deck Replacement

For Video Instructions, click here: Removing the Top Deck   Step 1- Remove the handle from the handle rests and place the handle in the full forward position as shown. Step 2- Stand the WaterRower upright and disconnect the bungee as shown. Step 3- Lay the WaterRower down. Remove the Tie Rods and JCB bolts …
